“40 years of senior mining machinery solutions”
Made in China
Two weeks delivery, custom cycle, please consult
Low operating cost:Compared with conventional mechanical agitation flotation machines,it can save 1/3-1/2 of electricity. High sorting accuracy and low ash content of clean coal:The ash content of clean coal can be reduced by 1~2%compared with conventional mechanical stirring flotation machines. Good flotation effect:It is equipped with automatic liquid level control and electronic control device,and the foam is highly refined,thus improving the flotation effect. The wearing parts are highly durable:the impeller is always active in the machine,which plays a role in removing accumulated materials and debris,reducing the damage to components due to debris;and the impeller of the mixing device is made of ground rubber. Enhanced wear resistance.
| Model | Trough volume （m³） |
Inside dimensions （L×W×H） （m） |
Air suction amount （m³·min） |
Power （kw） |
Motor model | Processing capacity （m³/min） |
| BF-0.37 | 0.37 | 0.74×0.74×0.75 | 0.9～1.05 | 1.5 | Y90L-4 | 0.2～0.4 |
| BF-0.65 | 0.65 | 0.85×0.95×0.9 | 0.9～1.10 | 3.0 | Y132S-6 | 0.3～0.7 |
| BF-1.2 | 1.2 | 1.05×1.15×1.10 | 1.0～1.10 | 5.5 4.0 |
Y132M2-6 Y132M1-6 |
0.6～1.2 |
| BF-2.0 | 2.0 | 1.40×1.45×1.12 | 1.0～1.10 | 7.5 | Y160M-6 | 1.0～2.0 |
| BF-2.8 | 2.8 | 1.65×1.65×1.15 | 0.9～1.10 | 11 | Y180L-8 | 1.4～3.0 |
| BF-4.0 | 4.0 | 1.9×2.0×1.2 | 0.9～1.10 | 15 | Y200L-8 | 2～4 |
| BF-6.0 | 6.0 | 2.2×2.35×1.3 | 0.9～1.10 | 18.5 | Y225S-8 | 3～6 |
| BF-8.0 | 8.0 | 2.25×2.85×1.4 | 0.9～1.10 | 22 30 |
Y225M-8 Y250M-8 |
4～8 |
| BF-10 | 10 | 2.25×2.85×1.7 | 0.9～1.10 | 22 30 |
Y225M-8 Y250M-8 |
5～10 |
| BF-16 | 16 | 2.85×3.8×1.7 | 0.9～1.10 | 37 45 |
Y280S-8 Y280M-8 |
8～16 |
| BF-20 | 20 | 2.85×3.8×2.0 | 0.9～1.10 | 37 45 |
Y280S-8 Y280M-8 |
10～20 |
| BF-24 | 24 | 3.15×4.15×2.0 | 0.9～1.10 | 45 | Y280M-8 | 12～24 |
| Model | Trough volume （m³） |
Processing capacity （m³/min） |
| BF-0.37 | 0.37 | 0.2～0.4 |
| BF-0.65 | 0.65 | 0.3～0.7 |
| BF-1.2 | 1.2 | 0.6～1.2 |
| BF-2.0 | 2.0 | 1.0～2.0 |
| BF-2.8 | 2.8 | 1.4～3.0 |
| BF-4.0 | 4.0 | 2～4 |
| BF-6.0 | 6.0 | 3～6 |
| BF-8.0 | 8.0 | 4～8 |
| BF-10 | 10 | 5～10 |
| BF-16 | 16 | 8～16 |
| BF-20 | 20 | 10～20 |
| BF-24 | 24 | 12～24 |
For customization, please contact us.
